Description
Applicable Fluid : Air (No other gased or liquids)
Working Temperature : -35 – 60 ͦC
| Model | O.D. | I.D | Length M/Roll | Color | Operating pressure |
Download |
| PUN-3×0.5 | 3mm | 2.1mm | 50 , 500 |
Silver
Blue Black Yellow Green Red |
(-0.95) +10 Bar
|
|
| PUN-4×0.75 | 4mm | 2.6mm | 50 , 500 | |||
| PUN-6×1 | 6mm | 4mm | 50 , 500 | |||
| PUN-8×1.25 | 8mm | 5.7mm | 50 , 400 | |||
| PUN-10×1.5 | 10mm | 7mm | 50 , 300 | |||
| PUN-12×2 | 12mm | 8mm | 50 , 200 | |||
| PUN-14×2 | 14mm | 9.8mm | 50 | |||
| PUN-16×2.5 | 16mm | 11mm | 50 , 100 |
